Cyclone Dust Collector

All-in-one type cyclone

1. A cyclone dust collector is a device that rotates a dusty airflow, separates dust particles from the airflow with the help of centrifugal force, and captures them on the wall of the dust collector. Then, with the help of gravity, the dust particles fall into the ash hopper.

2. The advantages of a cyclone are its simple structure, convenient use, no need for filter materials, and cost savings.

3. Side opening door, inserting or pulling out flat cloth bag, does not occupy top space, suitable for indoor and limited space installation.

3. Each component of a cyclone dust collector has a certain size ratio, and any change in the ratio relationship can affect the efficiency and pressure loss of the cyclone dust collector. Among them, the diameter of the dust collector, the size of the inlet, and the diameter of the exhaust pipe are the main influencing factors.

4. Modular manufacturing, modular assembly, and overall spray molding are used to meet the size of containers and can be shipped by sea to various parts of the world.

All-in-one type cyclone

1.1 Product Name: All-in-one type cyclone , air volume range： 500-6000CMH

1.2 A cyclone dust collector is a device that rotates a dusty airflow, uses centrifugal force to separate dust particles from the airflow, and captures them on the walls of the dust collector.

1.3 Then, with the help of gravity, dust particles fall into the ash hopper.

1.4 The advantage is that the structure is simple, no filtering materials are required, and the comprehensive cost of investment and use is saved.

1.5 Each component of a cyclone dust collector has a certain size ratio, and any change in the proportion relationship will affect the efficiency and pressure loss of the cyclone dust collector.

1.6 The diameter of the dust collector, the size of the inlet, and the diameter of the exhaust pipe are the main factors that affect the dust removal efficiency.

1.7 Tangential centrifugal force has a high dust removal efficiency for large particles and high-density dust.

1.8 Carbon steel material or stainless steel such as 304 and 316L can be selected, and wear-resistant ceramic or PTFE plastic anti-corrosion lining can be added to the inner wall.

1.9 Design service: Based on the size of your on-site space, design product drawings for free, and provide installation guidance and training services.

1.10 International transportation: Our product dimensions meet the requirements of container transportation, making it easy to transport to various parts of the world.
