1.1 The wet scrubber tower is manufactured from carbon steel or stainless steel plates to create a cylindrical spray tower structure. Ceramic packing media is used inside the tower to improve gas-liquid contact. Airflow capacity: 1000-100000 CMH.

1.2 The lower section works as a water tank, the middle section contains ceramic packing media, spray devices are installed above the packing layer, and the upper section is equipped with a demister for droplet separation.

1.3 The gas passes upward through the ceramic packing layer where it contacts the scrubbing liquid, improving the transfer of pollutants from gas phase to liquid phase.

1.4 Multiple spray stages and packing layers can be configured according to pollutant characteristics and treatment requirements for high concentration exhaust air applications.

1.5 Water or chemical scrubbing solutions can be selected according to the characteristics of target gases and treatment requirements.

1.6 Ceramic packing media provides stable performance and good temperature resistance for industrial wet scrubbing applications.

1.7 The packing layer can be configured with ceramic rings or other suitable packing materials according to different process requirements.

1.8 Multi-stage spraying design can enhance physical capture and gas-liquid contact performance for industrial exhaust treatment.

1.9 OEM customization support is available according to airflow requirements, installation conditions and pollutant characteristics.

1.10 The modular design allows convenient transportation and installation for international projects.
