1.1 The simplest and most practical scrubber is equipped with a bell shaped Venturi nozzle at the inlet of the scrubber tower. A dehydrator is installed inside the tower for dehydration, and a mud scraper is installed in the water tank to scrape out and collect the settled sludge. Air volume range: 3000-100000CMH.

1.2  Use a high-pressure water pump to atomize and spray in the Venturi pipeline, allowing smoke and water to mix and settle.

1.3 The gas rises and enters the defogging section, where it drips through the upper cyclone defogger. As the core of gas-liquid mass transfer is a corrugated plate.

1.4 The airflow undergoes a maze like inertial collision here, causing water droplets to continuously gather, remove them, and discharge clean airflow into the atmosphere.

1.5 Washing solution can be water or chemical solvents that can dissolve and absorb each other based on the characteristics of the gas.

1.6 Typically, acidic gas washing solutions are NaOH reagents that undergo acid-base neutralization chemical reactions to produce salts and water.

1.7 The Venturi scrubber usually does not require the installation of a packing layer, reducing the cost of investment and operation.

1.8  Use an automatic instrument to monitor the pH value of the washing solution. When pH<7 is found, NaOH reagent is automatically added to keep the washing solution between 7

1.9 Design Services: Based on the size of your on-site space, design product drawings for free, and provide installation guidance and training services.

1.10 International transportation: Our product dimensions meet the requirements of container transportation, making it easy to transport to various parts of the world.
